As a pvc waterstop manufacturer, Xinxirang can provide waterstop solution. Water stop products to solve all water stop.

Durable PVC WATERSTOPPER ZO-150 Outdoor Building Waterproofing 1

Durable PVC WATERSTOPPER ZO-150 Outdoor Building Waterproofing 2

Durable PVC WATERSTOPPER ZO-150 Outdoor Building Waterproofing 3

Durable PVC WATERSTOPPER ZO-150 Outdoor Building Waterproofing 4

Durable PVC WATERSTOPPER ZO-150 Outdoor Building Waterproofing

Durable Corrosion-Resistant PVC WATERSTOPPER ZO-150 - Ideal for Outdoor Building Walls

The product is particularly suitable for engineering projects with narrow joints and complex displacement demands, including:

Residential construction: Prefabricated shear wall connection joints, basement interior wall construction joints, small-sized retaining wall expansion seams, and balcony waterproof edge joints ;

Municipal engineering: Small rainwater regulation tanks, sewage lifting station internal joints, sidewalk expansion joints, and underground pipe trench connection seams ;

Light water conservancy projects: Small irrigation channel joints, farmland water conservancy pond circumferential seams, and small reservoir auxiliary structure joints ;

Light industrial facilities: Workshop floor narrow expansion joints, small storage tank (≤50m³) connection seams, and equipment foundation waterproof joints .

It performs stably in environments with low-to-medium water pressure (≤0.3MPa), frequent dry-wet alternations, or mild chemical corrosion (pH 4-9).

3. Installation and Advantages

Efficient and Convenient Installation: The 150mm narrow width and flexible material allow easy cutting and bending, adapting to linear, curved, and right-angle joints without special shaping tools. Installation can be completed using ordinary steel bar clamps or template pressing, with no need for complex fixing brackets. For joint connections, hot-melt welding (using a 300W PVC welding gun) or specialized PVC waterproof adhesive can be used, ensuring the integrity of the waterproof system. The product is highly compatible with the concrete pouring process, reducing the construction time of the joint waterproofing link by 20-25% compared to traditional wide-width waterstops.

Cost-Effective and Durable: With strong resistance to microbial erosion and insolubility in water, domestic sewage, and common industrial oils, the product maintains stable waterproof performance for over 35 years under normal use conditions, significantly reducing the frequency and cost of later maintenance and repair. Its narrow width design reduces material usage by 25-30% in narrow joint projects compared to 200mm-wide waterstops, and the simple installation process lowers labor costs, achieving overall project cost savings of 15-20%.

Reliable Quality Assurance: Each batch of products undergoes third-party testing for key indicators such as tensile strength, low-temperature flexibility, aging resistance, and chemical resistance, with a qualified rate of 100%. The finished products are packaged in 30m rolls (customizable according to project needs) with moisture-proof film, facilitating transportation and on-site storage. The product fully meets the acceptance standards of GB 50208-2022 Code for Acceptance of Construction Quality of Building Waterproofing Engineering and provides a 10-year quality guarantee commitment.

Material:

pvc

Color:

Yellow

Length:

200mm

Inquiry

Write a Review

Product description

Waterstop ZO150 offers superior waterproofing and durability for construction projects, ensuring reliable protection against water leakage. With its high-quality materials and advanced design, this waterstop provides long-lasting performance, easy installation, and resistance to water, chemicals, and UV rays. Trust WS0843E to deliver tight seals and prevent leaks in various construction applications.

Product parameter

● The FDA Extraction Toxicity Tests with 21 CFR 175.300. British Standards BS 2782:320A test results

Stan dardcom pliance
BS 2782:320A	Hong Kong General Specification for Civil Engineering Works clause 16.80
U.S.Corps of Engineers CRD-C572-74	China GB/T 1040-1992
Properties
Form	Extruded thermoplastic sections
Colour	Yellow
Solid content	100%
Density	1409kg/m3
Hardness	78.0IRHD
Tensile strength	14 N/mm2
Elongation at bleak point	300%
Toxicity	non-toxic1

Product Advantages

Durable PVC WATERSTOPPER ZO-150 Outdoor Building Waterproofing 7

Durability

The Waterstop ZO150 is designed with durable materials and advanced technology, ensuring long-lasting protection against water seepage.

Easy Installation

Its innovative design allows for easy installation and maintenance, saving time and effort for users.

Sealing Performance

With excellent sealing performance and reliability, the Waterstop ZO150 is the ideal solution for waterproofing projects in various settings.

Advanced Technology

The Waterstop ZO150 incorporates advanced technology to provide superior waterproofing capabilities, making it a top choice for water protection needs.

FAQ

What is the Waterstop ZO150 used for?

The Waterstop ZO150 is used to prevent water infiltration in concrete structures such as basements, tunnels, and reservoirs.

How is the Waterstop ZO150 installed?

The Waterstop ZO150 is typically installed by embedding it into the concrete joints during the construction phase.

What are the dimensions of the Waterstop ZO150?

The Waterstop ZO150 has a width of 8 inches and a height of 4 inches, with a standard length of 20 feet.

Can the Waterstop ZO150 be used in both horizontal and vertical applications?

Yes, the Waterstop ZO150 can be used in both horizontal and vertical concrete joints to effectively stop water infiltration.

Is the Waterstop ZO150 compatible with various types of concrete?

Yes, the Waterstop ZO150 is compatible with most common types of concrete, including regular concrete, shotcrete, and precast concrete.

How long does the Waterstop ZO150 last once installed?

The Waterstop ZO150 is designed to have a long lifespan and can effectively prevent water infiltration for many years, even in harsh environmental conditions.
